C5 Corvette Diagnostic Trouble Codes (DTCs) & Descriptions

Posted on by Dino Behler Jr.
C5 Corvette Diagnostic Trouble Codes (DTCs) & Descriptions Banner

What is a Diagnostic Trouble Code (DTC)?

A Diagnostic Trouble Code (DTC) is a systematic coding structure used by a Corvette to signal that an issue has occurred. Each DTC consists of one letter and four digits, such as B0605, and corresponds to a specific error/fault. When a component or system is not operating within acceptable limits, the Corvette will activate the appropriate DTC and store it within the Body Control Module (BCM). This code can be retrieved by the driver at any time to identify and fix any issue with the Corvette.

If you would like to read more about the on-board diagnostics and how to generate a list of your Diagnostic Trouble Codes, read this article.

Below you will find a table which includes the following information per row:

  1. The Diagnostic Trouble Code (DTC)
  2. The Diagnostic Trouble Code (DTC) Description
  3. The Corvette Module(s) related to the Diagnostic Trouble Code (DTC)
  4. The Corvette System(s) related to the Diagnostic Trouble Code (DTC)
  5. The Corvette years to which the Diagnostic Trouble Code (DTC) applies to

The table includes diagnostic trouble codes for the following systems:

  1. AntiLock Brake (ABS) / Traction Control
  2. Body Control
  3. Cruise Control
  4. Datalink Communications
  5. Doors
  6. Driver Information Center (DIC)
  7. Electronic Suspension Control
  8. Engine Controls
  9. Heater-Ventilation-Air-Conditioning (HVAC)
  10. Horns
  11. Hydraulic Brakes
  12. Instrument Panel, Gauges and Console
  13. Keyless Entry
  14. Lighting
  15. Seats
  16. Stationary Windows
  17. Steering Wheel and Column
  18. Supplemental Inflatable Restraint (SIR)
  19. Theft Deterrent
  20. Tire Pressure Monitor (TPMS)
  21. Transmission (Automatic and Manual)

If any Diagnostic Trouble Code (DTC) has been left out from this list, please comment the five digit code below and a Corvette Salvage Crew Member will add it to the list.

C5 Corvette Diagnostic Trouble Codes (DTCs) & Descriptions

Diagnostic Trouble Code (DTC) Description Module(s) System(s)
wdt_ID Diagnostic Trouble Code (DTC) Description Module(s) System(s) Applicable Years
1 B0016 RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1) RESISTANCE LOW SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
2 B0017 RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1) OPEN CIRCUIT SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
3 B0018 RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1) SHORT TO GROUND/VOLTAGE OUT OF RANGE SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
4 B0022 LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) RESISTANCE LOW SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
5 B0024 LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) SHORT TO GROUND/VOLTAGE OUT OF RANGE SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
6 B0026 LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) OPEN CIRCUIT SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
7 B0051 DEPLOYMENT COMMANDED SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
8 B0053 DEPLOYMENT COMMANDED WITH LOOP MALFUNCTIONS PRESENT SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
9 B0090 ACTIVE SWITCH VOLTAGE OUT OF RANGE SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
10 B0091 ACTIVE SWITCH: WRONG STATE SENSING AND DIAGNOSTIC MODULE (SDM) SUPPLEMENTAL INFLATABLE RESTRAINT (SIR) 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004

C5 Corvette Diagnostic Trouble Codes (DTCs) & Descriptions (Non-Searchable)

Diagnostic Trouble Code (DTC)Description
B0016RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1)
RESISTANCE LOW
B0017RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1) OPEN
CIRCUIT
B0018RIGHT FRONT/PASSENGER FRONTAL DEPLOYMENT LOOP (STAGE 1) SHORT TO
GROUND/VOLTAGE OUT OF RANGE
B0022LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) RESISTANCE
LOW
B0024LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) SHORT TO
GROUND/VOLTAGE OUT OF RANGE
B0026LEFT FRONT/DRIVER FRONTAL DEPLOYMENT LOOP (STAGE 1) OPEN CIRCUIT
B0051DEPLOYMENT COMMANDED
B0053DEPLOYMENT COMMANDED WITH LOOP MALFUNCTIONS PRESENT
B0090ACTIVE SWITCH VOLTAGE OUT OF RANGE
B0091ACTIVE SWITCH: WRONG STATE
B0332OUTSIDE AIR TEMP SENSOR SHORT TO GND
B0333OUTSIDE AIR TEMP SENSOR OPEN
B0337INSIDE AIR TEMP SENSOR SHORT TO GND
B0338INSIDE AIR TEMP SENSOR OPEN
B0348SUN LOAD TEMPERATURE SENSOR OPEN
B0361LEFT ACTUATOR FEEDBACK SHORT TO GND
B0363LEFT ACTUATOR FEEDBACK OPEN
B0365RIGHT ACTUATOR FEEDBACK SHORT TO GND
B0367RIGHT ACTUATOR FEEDBACK OPEN
B0432REAR DEFOGGER RELAY CIRCUIT
B0433REAR DEFOGGER RELAY CIRCUIT
B0441LEFT HEATER-VENTILATION-AIR CONDITIONING (HVAC) ACTUATOR OUT OF RANGE
B0446RIGHT HEATER-VENTILATION-AIR CONDITIONING (HVAC) ACTUATOR OUT OF RANGE
B0502RH DRL RELAY CIRCUIT
B0503RH DRL RELAY CIRCUIT
B0507LH DRL RELAY CIRCUIT
B0508LH DRL RELAY CIRCUIT
B0516SPEEDOMETER SIGNAL CIRCUIT MALFUNCTION
B0521TACHOMETER SIGNAL CIRCUIT MALFUNCTION
B0605BODY CONTROL MODULE (BCM) INTERNAL MEMORY MALFUNCTION
B0846BATTERY 2 OUT OF RANGE
B0851BATTERY 1 OUT OF RANGE
B08565 VOLT REFERENCE OUT OF RANGE
B1000ECU MALFUNCTION
B1001OPTION CONFIGURATION ERROR
B1512DRIVER INFORMATION CENTER (DIC) SWITCH 1 SIGNAL SHORT TO GND “FUEL”
B1517DRIVER INFORMATION CENTER (DIC) SWITCH 2 SIGNAL SHORT TO GND “GAGES”
B1522DRIVER INFORMATION CENTER (DIC) SWITCH 3 SIGNAL SHORT TO GND “TRIP”
B1527DRIVER INFORMATION CENTER (DIC) SWITCH 4 SIGNAL SHORT TO GND “OPTIONS”
B1532DRIVER INFORMATION CENTER (DIC) SWITCH 5 SIGNAL SHORT TO GND “E/M”
B1537DRIVER INFORMATION CENTER (DIC) SWITCH 6 SIGNAL SHORT TO GND “RESET
B1542OIL TEMPERATURE CIRCUIT SHORT TO GROUND
B1543OIL TEMPERATURE CIRCUIT OPEN
B2002FORE/AFT SEAT MOTOR OPEN OR SHORT TO GND
B2007FRONT VERTICAL SEAT MOTOR OPEN OR SHORTED
B2012REAR VERTICAL SEAT MOTOR OPEN OR SHORTED
B2172SEAT FRONT UP SWITCH SHORTED TO GND
B2177SEAT FRONT DOWN SWITCH SHORTED TO GND
B2182SEAT REAR UP SWITCH SHORTED TO GND
B2187SEAT REAR DOWN SWITCH SHORTED TO GND
B2192SEAT FORWARD SWITCH SHORTED TO GND
B2197SEAT REVERSE SWITCH SHORTED TO GND
B2202LEFT WINDOW UP SWITCH FAULT
B2203RIGHT WINDOW UP SWITCH FAULT
B2204LEFT WINDOW DOWN SWITCH FAULT
B2205RIGHT WINDOW DOWN SWITCH FAULT
B2206RIGHT WINDOW UP SWITCH FAULT
B2208RIGHT WINDOW DOWN SWITCH FAULT
B2222LT MIRROR SELECT SWITCH FAULT
B2224RT MIRROR SELECT SWITCH FAULT
B2226MIRROR RIGHT SWITCH FAULT
B2228MIRROR LEFT SWITCH FAULT
B2232MIRROR UP SWITCH FAULT
B2234MIRROR DOWN SWITCH FAULT
B2236LEFT DOOR LOCK SWITCH FAULT
B2237RIGHT DOOR LOCK SWITCH FAULT
B2238LEFT DOOR UNLOCK SWITCH FAULT
B2239RIGHT DOOR UN‐LOCK SWITCH FAULT
B2242MEMORY 1 SWITCH FAULT
B2244MEMORY 2 SWITCH FAULT
B2252KEY CYLINDER SWITCH FAULT
B2253KEY CYLINDER SWITCH FAULT
B2262MIRROR HORIZONTAL POSITION SENSOR FAULT
B2263MIRROR HORIZONTAL POSITION SENSOR FAULT
B2264MIRROR VERTICAL POSITION SENSOR FAULT
B2265MIRROR VERTICAL POSITION SENSOR FAULT
B2272LEFT MIRROR MOTOR FAULT
B2273RIGHT MIRROR MOTOR FAULT
B2274WINDOW MOTOR FAULT
B2275WINDOW MOTOR FAULT
B2276DOOR LOCK MOTOR/MIRROR HEATER FAULT
B2277DOOR LOCK MOTOR/MIRROR HEATER FAULT
B2278OVERCURRENT CONDITION IN SWITCH BACKLIGHTING OUTPUT
B2279OVERCURRENT CONDITION IN SWITCH BACKLIGHTING OUTPUT
B228212V POWER FEED #1 FAULT
B228312V POWER FEED #1 FAULT
B228412V POWER FEED #2 FAULT
B228512V POWER FEED #2 FAULT
B2286+5V REFERENCE FAULT
B2287+5V REFERENCE FAULT
B2403FRONT FOG LAMP SWITCH CIRCUIT
B2408REAR FOG LAMP SWITCH CIRCUIT
B2482BACKUP LAMP RELAY CIRCUIT
B2483BACKUP LAMP RELAY CIRCUIT
B2527HORN RELAY CIRCUIT
B2528HORN RELAY CIRCUIT
B2567FOLDING TOP RELEASE SWITCH CIRCUIT
B2573HATCH RELEASE SWITCH CIRCUIT
B2578RIGHT FRONT TURN SIGNAL MONITOR CIRCUIT
B2583LEFT FRONT TURN SIGNAL MONITOR CIRCUIT
B2587COLUMN LOCK  OPEN OR SHORT TO GND
B2588COLUMN LOCK  OPEN OR SHORT TO VOLTAGE
B2592COLUMN UNLOCK OPEN OR SHORT TO GND
B2593COLUMN UNLOCK OPEN OR SHORT TO VOLTAGE
B2597TRACTION CONTROL SYSTEM SWITCH CIRCUIT
B2600SEAT MOTOR TO BATTERY VOLTAGE
B2605SEAT FRONT VERTICAL POSITION SENSOR FAILURE
B2606SEAT REAR VERTICAL POSITION SENSOR FAILURE
B2607SEAT HORIZONTAL POSITION SENSOR FAILURE
B2647AMBIENT LIGHT SENSOR CIRCUIT LOW
B2648AMBIENT LIGHT SENSOR CIRCUIT HIGH
B2721PASS‐KEY DETECTION CIRCUIT
B2722PASS‐KEY DETECTION CIRCUIT
B2723PASS‐KEY DETECTION CIRCUIT
B2735PASS‐KEY PROGRAMMING MODE ACTIVE
B2795SUSPENSION CONTROL SELECT SWITCH CIRCUIT MALFUNCTION
B2805NO TRANSMITTERS PROGRAMMED
B2852TELESCOPING COLUMN IN SWITCH SHORTED TO GROUND
B2857TELESCOPING COLUMN OUT SWITCH SHORTED TO GROUND
B2860TELESCOPING COLUMN POSITION SENSOR FAILURE
B3109KEYLESS ENTRY TRANSMITTER LOW BATTERY
B3577SUSPENSION CONTROL SELECT SWITCH CONTACT MALFUNCTION
C0550ECU INTERNAL MALFUNCTION
C0563CALIBRATION ROM CHECKSUM ERROR
C0577LF SUSPENSION ACTUATOR CIRCUIT
C0578LF SUSPENSION ACTUATOR CIRCUIT HIGH
C0579RF SUSPENSION ACTUATOR CIRCUIT
C0582LR SUSPENSION ACTUATOR CIRCUIT
C0583RF SUSPENSION ACTUATOR CIRCUIT HIGH
C0584RR SUSPENSION ACTUATOR CIRCUIT
C0587SUSPENSION ACTUATOR CIRCUIT
C0588LR SUSPENSION ACTUATOR CIRCUIT HIGH
C0589SUSPENSION ACTUATOR CIRCUIT
C0592SUSPENSION ACTUATOR CIRCUIT
C0593RR SUSPENSION ACTUATOR CIRCUIT HIGH
C0594SUSPENSION ACTUATOR CIRCUIT
C0615LF SUSPENSION POSITION SENSOR CIRCUIT
C0620RF SUSPENSION POSITION SENSOR CIRCUIT
C0625LR SUSPENSION POSITION SENSOR CIRCUIT
C0630RR SUSPENSION POSITION SENSOR CIRCUIT
C0665CHASSIS PITCH SIGNAL CIRCUIT
C0690DAMPER CONTROL RELAY CIRCUIT
C0691DAMPER CONTROL RELAY CIRCUIT
C0693DAMPER CONTROL RELAY CIRCUIT
C0695POSITION SENSOR OVERCURRENT (8 VOLT SUPPLY)
C0710STEERING POSITION SIGNAL MALFUNCTION
C0750LF TIRE PRESSURE SENSOR CIRCUIT
C0755RF TIRE PRESSURE SENSOR CIRCUIT
C0760LR TIRE PRESSURE SENSOR CIRCUIT
C0765RR TIRE PRESSURE SENSOR CIRCUIT
C1214SOLENOID VALVE RELAY CONTACT OR COIL CIRCUIT OPEN
C1217PUMP MOTOR RELAY CONTACT CIRCUIT OPEN
C1218PUMP MOTOR CIRCUIT SHORTED TO VOLTAGE OR MOTOR GROUND OPEN
C1221LF WHEEL SPEED SENSOR INPUT SIGNAL IS 0
C1222RF WHEEL SPEED SENSOR INPUT SIGNAL IS 0
C1223LR WHEEL SPEED SENSOR INPUT SIGNAL IS 0
C1224RR WHEEL SPEED SENSOR INPUT SIGNAL IS 0
C1225LF EXCESSIVE WHEEL SPEED VARIATION
C1226RF EXCESSIVE WHEEL SPEED VARIATION
C1227LR EXCESSIVE WHEEL SPEED VARIATION
C1228RR EXCESSIVE WHEEL SPEED VARIATION
C1232LF WHEEL SPEED CIRCUIT OPEN OR SHORTED
C1233RF WHEEL SPEED CIRCUIT OPEN OR SHORTED
C1234LR WHEEL SPEED CIRCUIT OPEN OR SHORTED
C1235RR WHEEL SPEED CIRCUIT OPEN OR SHORTED
C1236LOW SYSTEM SUPPLY VOLTAGE
C1237HIGH SYSTEM SUPPLY VOLTAGE
C1241MAGNA STEER CIRCUIT MALFUNCTION
C1242BRAKE PRESSURE MODULATOR VALVE PUMP MOTOR GROUND CIRCUIT OPEN
C1243BRAKE PRESSURE MODULATOR VALVE PUMP MOTOR STALLED
C1247BRAKE PRESSURE DIFFERENTIAL SWITCH ACTIVATED
C1248DYNAMIC REAR PROPORTIONING (DRP) DISABLED
C1254ABNORMAL SHUTDOWN DETECTED
C1255ECU MALFUNCTION
C1256ECU MALFUNCTION
C1261LF INLET VALVE SOLENOID MALFUNCTION
C1262LF OUTLET VALVE SOLENOID MALFUNCTION
C1263RF INLET VALVE SOLENOID MALFUNCTION
C1264RF OUTLET VALVE SOLENOID MALFUNCTION
C1265LR INLET VALVE SOLENOID MALFUNCTION
C1266LR OUTLET VALVE SOLENOID MALFUNCTION
C1267RR INLET VALVE SOLENOID MALFUNCTION
C1268RR OUTLET VALVE SOLENOID MALFUNCTION
C1271LF TRACTION CONTROL SYSTEM (TCS) MASTER CYLINDER ISOLATION VALVE MALFUNCTION
C1272LF TRACTION CONTROL SYSTEM (TCS) VALVE SOLENOID MALFUNCTION ABS ABS/TRACTION CONTROL SYSTEM (TCS)/DRIVER INFORMATION CENTER (DIC)
C1273RF TRACTION CONTROL SYSTEM (TCS) MASTER CYL ISOLATION VALVE MALFUNCTION
C1274RF TRACTION CONTROL SYSTEM (TCS) PRIME VALVE MALFUNCTION
C1276DELIVERED TORQUE SIGNAL CKT MALFUNCTION
C1277REQUESTED TORQUE SIGNAL CKT MALFUNCTION
C1278TRACTION CONTROL SYSTEM (TCS) TEMPORARILY INHIBITED BY POWERTRAIN CONTROL MODULE (PCM)
C1281STEERING SENSOR UNCORRELATED MALFUNCTION
C1282YAW RATE SENSOR BIAS CIRCUIT MALFUNCTION
C1283STEERING SENSOR UNCORRELATED MALFUNCTION
C1284LATERAL ACCELEROMETER CIRCUIT
C1285LATERAL ACCELEROMETER CIRCUIT
C1286STEERING SENSOR BIAS MALFUNCTION
C1287STEERING SENSOR RATE MALFUNCTION
C1288STEERING POSITION SENSOR CIRCUIT
C1291OPEN BRAKE LAMP CIRCUIT DURING DECELEATION
C1292MASTER CYLINDER PRESSURE SENSOR CIRCUIT
C1293MASTER CYLINDER PRESSURE SENSOR CIRCUIT
C1294BRAKE LAMP SWITCH CIRCUIT ALWAYS ACTIVE
C1295BRAKE LAMP SWITCH CIRCUIT OPEN
C1296MASTER CYLINDER PRESSURE SENSOR CIRCUIT
LEFT FRONT TIRE PRESSURE MONITOR (TPM) SENSOR MALFUNCTION                                                     REMOTE FUNCTION ACTUATION (RFA)/TIRE PRESSURE MONITOR (TPM)
C2100LEFT FRONT TIRE PRESSURE MONITOR (TPM) SENSOR MALFUNCTION
C2105RIGHT FRONT TIRE PRESSURE MONITOR (TPM) SENSOR MALFUNCTION
C2110RIGHT REAR TIRE PRESSURE MONITOR (TPM) SENSOR MALFUNCTION
C2115LEFT REAR TIRE PRESSURE MONITOR (TPM) SENSOR MALFUNCTION
C2120TIRE PRESSURE MONITOR (TPM) SYSTEM MALFUNCTION
C2121TIRE PRESSURE MONITOR (TPM) SYSTEM PROGRAMMING MALFUNCTION
P0101MASS AIR FLOW (MAF) SENSOR PERFORMANCE
P0102MASS AIR FLOW (MAF) SENSOR CIRCUIT LOW FREQUENCY
P0103MASS AIR FLOW (MAF) SENSOR CIRCUIT HIGH FREQUENCY
P0106MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR PERFORMANCE
P0107MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR CIRCUIT LOW VOLTAGE
P0108MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR CIRCUIT HIGH VOLTAGE
P0112INTAKE AIR TEMPERATURE (IAT) SENSOR CIRCUIT LOW VOLTAGE
P0113INTAKE AIR TEMPERATURE (IAT) SENSOR CIRCUIT HIGH VOLTAGE
P0116ENGINE COOLANT TEMPERATURE (ECT) SENSOR PERFORMANCE
P0117ENGINE COOLANT TEMPERATURE (ECT) SENSOR CIRCUIT LOW VOLTAGE
P0118ENGINE COOLANT TEMPERATURE (ECT) SENSOR CIRCUIT HIGH VOLTAGE
P0120THROTTLE/PEDAL POSITION SENSOR/SWITCH “A” CIRCUIT
P0125ENGINE COOLANT TEMPERATURE (ECT) INSUFFICIENT FOR CLOSED LOOP FUEL
CONTROL
P0128ENGINE COOLANT TEMPERATURE (ECT) BELOW THERMOSTAT REGULATING
TEMPERATURE
P0131HO2S CIRCUIT LOW VOLTAGE BANK 1 SENSOR 1
P0132HO2S CIRCUIT HIGH VOLTAGE BANK 1 SENSOR 1
P0133HO2S SLOW RESPONSE BANK 1 SENSOR 1
P0134HO2S CIRCUIT INSUFFICIENT ACTIVITY BANK 1 SENSOR 1
P0135HO2S HEATER PERFORMANCE BANK 1 SENSOR 1
P0136HO2S CIRCUIT
P0137HO2S CIRCUIT LOW VOLTAGE BANK 1 SENSOR 2
P0138HO2S CIRCUIT HIGH VOLTAGE BANK 1 SENSOR 2
P0140HO2S CIRCUIT INSUFFICIENT ACTIVITY BANK 1 SENSOR 2
P0141HO2S HEATER PERFORMANCE BANK 1 SENSOR 2
P0151HO2S CIRCUIT LOW VOLTAGE BANK 2 SENSOR 1
P0152HO2S CIRCUIT HIGH VOLTAGE BANK 2 SENSOR 1
P0153HO2S SLOW RESPONSE BANK 2 SENSOR 1
P0154HO2S CIRCUIT INSUFFICIENT ACTIVITY BANK 2 SENSOR 1
P0155HO2S HEATER PERFORMANCE BANK 2 SENSOR 1
P0156HO2S CIRCUIT
P0157HO2S CIRCUIT LOW VOLTAGE BANK 2 SENSOR 2
P0158HO2S CIRCUIT HIGH VOLTAGE BANK 2 SENSOR 2
P0160HO2S CIRCUIT INSUFFICIENT ACTIVITY BANK 2 SENSOR 2
P0161HO2S HEATER PERFORMANCE BANK 2 SENSOR 2
P0171FUEL TRIM SYSTEM LEAN BANK 1
P0172FUEL TRIM SYSTEM RICH BANK 1
P0174FUEL TRIM SYSTEM LEAN BANK 2
P0175FUEL TRIM SYSTEM RICH BANK 2
P0200INJECTOR CONTROL CIRCUIT
P0218TRANSMISSION FLUID OVER TEMPERATURE
P0220THROTTLE POSITION SENSOR CIRCUIT
P0230FUEL PUMP RELAY CONTROL CIRCUIT
P0300ENGINE MISFIRE DETECTED
P0315CRANKSHAFT POSITION SYSTEM VARIATION NOT LEARNED
P0325KNOCK SENSOR MODULE PERFORMANCE
P0327KNOCK SENSOR (KS) CIRCUIT LESS THAN EXPECTED FRONT
P0332KNOCK SENSOR (KS) CIRCUIT LESS THAN EXPECTED REAR
P0335CRANKSHAFT POSITION (CKP) SENSOR CIRCUIT
P0336CRANKSHAFT POSITION (CKP) SENSOR PERFORMANCE
P0341CAMSHAFT POSITION (CMP) SENSOR PERFORMANCE
P0342CAMSHAFT POSITION (CMP) SENSOR CIRCUIT LOW VOLTAGE
P0343CAMSHAFT POSITION (CMP) SENSOR CIRCUIT HIGH VOLTAGE
P0351IGNITION COIL CONTROL #1 CIRCUIT
P0352IGNITION COIL CONTROL #2 CIRCUIT
P0353IGNITION COIL CONTROL #3 CIRCUIT
P0354IGNITION COIL CONTROL #4 CIRCUIT
P0355IGNITION COIL CONTROL #5 CIRCUIT
P0356IGNITION COIL CONTROL #6 CIRCUIT
P0357IGNITION COIL CONTROL #7 CIRCUIT
P0358IGNITION COIL CONTROL #8 CIRCUIT
P0410SECONDARY AIR INJECTION (AIR) SYSTEM
P0412SECONDARY AIR INJECTION (AIR) PUMP RELAY CONTROL CIRCUIT
P0418SECONDARY AIR INJECTION (AIR) PUMP RELAY CONTROL CIRCUIT
P0420CATALYST SYSTEM LOW EFFICIENCY
P0430CATALYST SYSTEM LOW EFFICIENCY
P0440EVAPORATIVE EMISSION (EVAP) SYSTEM
P0442EVAPORATIVE EMISSION (EVAP) SYSTEM SMALL LEAK DETECTED
P0443EVAPORATIVE EMISSION (EVAP) PURGE SOLENOID CONTROL CIRCUIT
P0446EVAPORATIVE EMISSION (EVAP) VENT SYSTEM PERFORMANCE
P0449EVAPORATIVE EMISSION (EVAP) VENT SOLENOID CONTROL CIRCUIT
P0452FUEL TANK PRESSURE SENSOR CIRCUIT LOW VOLTAGE
P0453FUEL TANK PRESSURE SENSOR CIRCUIT HIGH VOLTAGE
P0461FUEL LEVEL SENSOR PERFORMANCE (NOTE: THE 1997 THROUGH 2002 AND EARLY BUILT 2003 CORVETTES WITHOUT THE FFS SYSTEM DID NOT HAVE A SECONDARY REGULATOR WHICH PREVENTS THE SIPHONING OF FUEL (LH TO RH) AFTER THE VEHICLE IS TURNED OFF. ALL CORVETTES WITH VEHICLE IDENTIFICATION NUMBER 35111542 AND ABOVE ARE EQUIPPED WITH THE FFS FUEL SYSTEM)
P0462FUEL LEVEL SENSOR CIRCUIT LOW VOLTAGE
P0463FUEL LEVEL SENSOR CIRCUIT HIGH VOLTAGE
P0480COOLING FAN RELAY 1 CONTROL CIRCUIT
P0481COOLING FAN RELAY 2 AND 3 CONTROL CIRCUIT
P0491SECONDARY AIR INJECTION (AIR) SYSTEM
P0492SECONDARY AIR INJECTION (AIR) SYSTEM
P0496EVAPORATIVE EMISSION SYSTEM HIGH PURGE FLOW
P0500VEHICLE SPEED SENSOR (VSS) CIRCUIT
P0502VEHICLE SPEED SENSOR (VSS) CIRCUIT LOW INPUT
P0503VEHICLE SPEED SENSOR (VSS) CIRCUIT INTERMITTENT
P0506INCORRECT IDLE SPEED
P0507INCORRECT IDLE SPEED
P0522ENGINE OIL PRESSURE (EOP) SENSOR CIRCUIT LOW VOLTAGE
P0523ENGINE OIL PRESSURE (EOP) SENSOR CIRCUIT HIGH VOLTAGE
P0530AIR CONDITIONING (A/C) REFRIGERANT PRESSURE SENSOR CIRCUIT
P0562POWERTRAIN CONTROL MODULE (PCM) SYSTEM VOLTAGE LOW
P0563POWERTRAIN CONTROL MODULE (PCM) SYSTEM VOLTAGE HIGH
P0567CRUISE CONTROL RESUME SWITCH CIRCUIT
P0568CRUISE CONTROL SET SWITCH CIRCUIT
P0571CRUISE CONTROL BRAKE SWITCH CIRCUIT
P0601POWERTRAIN CONTROL MODULE (PCM) MEMORY
P0602POWERTRAIN CONTROL MODULE (PCM) NOT PROGRAMMED
P0604POWERTRAIN CONTROL MODULE (PCM) RAM PERFORMANCE
P0606POWERTRAIN CONTROL MODULE (PCM) INTERNAL COMMUNICATION INTERRUPTED
P0608VEHICLE SPEED OUTPUT CIRCUIT
P0622GENERATOR FIELD/F TERMINAL CIRCUIT
P0641SENSOR REFERENCE VOLTAGE “A” CIRCUIT/OPEN
P0645AIR CONDITIONING (A/C) CLUTCH RELAY CONTROL CIRCUIT
P0650MALFUNCTION INDICATOR LAMP (MIL) CONTROL CIRCUIT
P0651SENSOR REFERENCE VOLTAGE “B” CIRCUIT/OPEN
P0654ENGINE SPEED OUTPUT CIRCUIT
P0704CLUTCH SWITCH CIRCUIT
P0705TRANSMISSION RANGE SWITCH CIRCUIT
P0706TRANSMISSION RANGE SWITCH PERFORMANCE
P0711TFT SENSOR CIRCUIT RANGE/PERFORMANCE
P0712TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR CIRCUIT LOW INPUT
P0713TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR CIRCUIT HIGH INPUT
P0719BRAKE SWITCH CIRCUIT LOW INPUT
P0724BRAKE SWITCH CIRCUIT HIGH INPUT
P0740TCC ENABLE SOLENOID CIRCUIT ELECTRICAL
P0742TCC SYSTEM STUCK ON
P0748PRESSURE CONTROL SOLENOID CIRCUIT ELECTRICAL
P07511‐2 SHIFT SOLENOID VALVE PERFORMANCE
P07521‐2 SHIFT SOLENOID (SS) VALVE PERFORMANCE ‐ NO SECOND OR THIRD
GEAR
P07531‐2 SHIFT SOLENOID CIRCUIT ELECTRICAL
P07562‐3 SHIFT SOLENOID VALVE PERFORMANCE
P07572‐3 SHIFT SOLENOID (SS) VALVE PERFORMANCE ‐ NO THIRD OR FOURTH GEAR
P07582‐3 SHIFT SOLENOID CIRCUIT ELECTRICAL
P07853‐2 SHIFT SOLENOID CIRCUIT ELECTRICAL
P0801REVERSE INHIBIT SOLENOID CONTROL CIRCUIT
P0803SKIP SHIFT SOLENOID CONTROL CIRCUIT
P0804SKIP SHIFT LAMP CONTROL CIRCUIT
P0833CLUTCH PEDAL SWITCH “B” CIRCUIT
P0894TRANSMISSION COMPONENT SLIPPING
P1111INTAKE AIR TEMPERATURE (IAT) SENSOR CIRCUIT INTERMITTENT HIGH
VOLTAGE
P1112INTAKE AIR TEMPERATURE (IAT) SENSOR CIRCUIT INTERMITTENT LOW
VOLTAGE
P1114ENGINE COOLANT TEMPERATURE (ECT) SENSOR CIRCUIT INTERMITTENT LOW
VOLTAGE
P1115ENGINE COOLANT TEMPERATURE (ECT) SENSOR CIRCUIT INTERMITTENT HIGH
VOLTAGE
P1120THROTTLE POSITION (TP) SENSOR 1 CIRCUIT
P1125ACCELERATOR PEDAL POSITION (APP) SYSTEM
P1133HO2S INSUFFICIENT SWITCHING
P1134HO2S TRANSITION TIME RATIO
P1153HO2S INSUFFICIENT SWITCHING
P1154HO2S TRANSITION TIME RATIO
P1220THROTTLE POSITION (TP) SENSOR 2 CIRCUIT
P1221THROTTLE POSITION (TP) SENSOR 1‐ 2 CORRELATION
P1258ENGINE COOLANT OVER TEMPERATURE ‐ PROTECTION MODE ACTIVE
P1275ACCELERATOR PEDAL POSITION (APP) SENSOR 1 CIRCUIT
P1276ACCELERATOR PEDAL POSITION (APP) SENSOR 1 PERFORMANCE
P1280ACCELERATOR PEDAL POSITION (APP) SENSOR 2 CIRCUIT
P1281ACCELERATOR PEDAL POSITION (APP) SENSOR 2 PERFORMANCE
P1285ACCELERATOR PEDAL POSITION (APP) SENSOR 3 CIRCUIT
P1286ACCELERATOR PEDAL POSITION (APP) SENSOR 3 PERFORMANCE
P1336CRANKSHAFT POSITION (CKP) SYSTEM VARIATION NOT LEARNED
P1380MISFIRE DETECTED ‐ ROUGH ROAD DATA NOT AVAILABLE
P1381MISFIRE DETECTED ‐ NO COMMUNICATION WITH BRAKE CONTROL MODULE
P1415SECONDARY AIR INJECTION (AIR) SYSTEM
P1416SECONDARY AIR INJECTION (AIR) SYSTEM
P1431FUEL LEVEL SENSOR 2 PERFORMANCE
P1432FUEL LEVEL SENSOR 2 CIRCUIT LOW VOLTAGE
P1433FUEL LEVEL SENSOR 2 CIRCUIT HIGH VOLTAGE
P1441EVAPORATIVE EMISSION (EVAP) SYSTEM FLOW DURING NON‐PURGE
P1514THROTTLE BODY PERFORMANCE
P1515CONTROL MODULE THROTTLE ACTUATOR POSITION PERFORMANCE
P1516THROTTLE ACTUATOR CONTROL (TAC) MODULE THROTTLE ACTUATOR POSITION
PERFORMANCE
P1517THROTTLE ACTUATOR CONTROL (TAC) MODULE PERFORMANCE
P1518THROTTLE ACTUATOR CONTROL (TAC) MODULE SERIAL DATA CIRCUIT
P1539AIR CONDITIONING (A/C) CLUTCH FEEDBACK CIRCUIT HIGH VOLTAGE
P1546AIR CONDITIONING (A/C) CLUTCH FEEDBACK CIRCUIT LOW VOLTAGE
P1571TORQUE SIGNAL IS OUT OF THE VALID RANGE (SEE C1277)
P1574STOPLAMP SWITCH CIRCUIT
P1575EXTENDED TRAVEL BRAKE SWITCH CIRCUIT
P1600POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1621POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1626THEFT DETERRENT FUEL ENABLE SIGNAL LOST
P1627POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1630THEFT DETERRENT LEARN MODE ACTIVE
P1631THEFT DETERRENT START ENABLE SIGNAL NOT CORRECT
P16355 VOLT REFERENCE 1 CIRCUIT
P1637GENERATOR L‐TERMINAL CIRCUIT
P1638GENERATOR F‐TERMINAL CIRCUIT
P16395 VOLT REFERENCE 2 CIRCUIT
P1652POWERTRAIN INDUCED CHASSIS PITCH OUTPUT CIRCUIT
P1680POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1681POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1683POWERTRAIN CONTROL MODULE (PCM) MEMORY
P1689THE DELIVERED TORQUE SIGNAL VOLTAGE IS INVALID (SEE C1276)
P1810TFP VALVE POSITION SWITCH CIRCUIT
P1860TCC PWM SOLENOID CIRCUIT ELECTRICAL SHORT TO GND
P1870TRANSMISSION COMPONENT SLIPPING
P2066FUEL LEVEL SENSOR “B” PERFORMANCE
P2067FUEL LEVEL SENSOR “B” CIRCUIT LOW
P2068FUEL LEVEL SENSOR “B” CIRCUIT HIGH
P2101THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE/PERFORMANCE
P2108THROTTLE ACTUATOR CONTROL MODULE PERFORMANCE
P2120THROTTLE/PEDAL POSITION SENSOR/SWITCH “D” CIRCUIT
P2121THROTTLE/PEDAL POSITION SENSOR/SWITCH “D” CIRCUIT RANGE/PERFORMANCE
P2125THROTTLE/PEDAL POSITION SENSOR/SWITCH “E” CIRCUIT
P2126THROTTLE/PEDAL POSITION SENSOR/SWITCH “E” CIRCUIT RANGE/PERFORMANCE
P2130THROTTLE/PEDAL POSITION SENSOR/SWITCH “F” CIRCUIT
P2131THROTTLE/PEDAL POSITION SENSOR/SWITCH “F” CIRCUIT RANGE
PERFORMANCE
P2610POWERTRAIN CONTROL MODULE (PCM) MEMORY
P2761TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID CONTROL CIRCUIT/OPEN
U1000CLASS 2 COMMUNICATION MALFUNCTION
U1001LOST COMMUNICATION WITH XXX
U1016NORMAL SOFTWARE FUNCTION,  HISTORY STATUS UPON IGNITION CYCLING
U1064NORMAL SOFTWARE FUNCTION,  HISTORY STATUS UPON IGNITION CYCLING
U1088LOSS OF COMMUNICATIONS WITH SENSING AND DIAGNOSTIC MODULE (SDM). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC)
U1096NORMAL SOFTWARE FUNCTION,  HISTORY STATUS UPON IGNITION CYCLING
U1128LOSS OF COMMUNICATIONS WITH RADIO. REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC)
U1153LOSS OF COMMUNICATIONS WITH HEATER-VENTILATION-AIR CONDITIONING (HVAC). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC)
U1160LOSS OF COMMUNICATIONS WITH LEFT DOOR CONTROL MODULE (LDCM). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC), RADIO
U1161LOSS OF COMMUNICATIONS WITH RIGHT DOOR CONTROL MODULE (RDCM). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC), RADIO
U1254LOST COMMUNICATION WITH XXX
U1166LOSS OF COMMUNICATIONS WITH SEAT CONTROL MODULE (SCM). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC)
U1176LOSS OF COMMUNICATIONS WITH REMOTE FUNCTION ACTUATION (RFA). REFER TO DTC U1001‐U1254 LOST COMMUNICATION WITH XXX INSTRUMENT PANEL CLUSTER (IPC)
U1255LOST COMMUNICATION WITH XXX
U1300LOW VOLTAGE ON THE CLASS 2 SERIAL DATA CIRCUIT.
U1301HIGH VOLTAGE ON THE CLASS 2 SERIAL DATA CIRCUIT.
U1305LOW VOLTAGE OR HIGH VOLTAGE ON THE CLASS 2 SERIAL DATA CIRCUIT
© Dino’s Corvette Salvage, LLC
Dino Behler Jr.

Leave a Reply
