C3 New LED Digital Gauge Panel 1968-1977

This part is a new aftermarket C3 LED Digital Gauge Panel.

Body and trim: Base, Stingray

1968-1977 Corvette LED Digital Gauge Panel

Upgrade your 1968-77 Corvette with the Intellitronix Direct-Fit LED Digital Gauge Replacement Dash Panel—a modern, high-performance display designed for seamless integration. This digital panel includes direct-fit printed circuit boards, a custom "smoked" plexiglass faceplate, and essential sending units for temperature, oil pressure, and speedometer (compatible with vehicles without electronic transmission or cruise control). Comprehensive installation instructions are also included.

Key Features:

• Speedometer: Displays up to 255 MPH, featuring an odometer, trip meter, one-button calibration (works with any tire size, gear ratio, or transmission), plus 0-60 time, ¼-mile elapsed time, and high-speed recall at the push of a button. Works with electronic cruise control senders or the S9013 universal speedometer sending unit for vehicles without functional cruise control.
• Tachometer: Displays 0-9999 RPM in 100, 10, or 1 RPM increments (e.g., 9900, 9990, 9999).
• Water Temperature: Reads 100-300°F and includes sending unit S8013. Please specify at checkout if you need a 3/8" bushing instead of the included 1/2" bushing. Otherwise, you will need to purchase it separately.
• Oil Pressure: Displays 0-100 PSI, including a sending unit.
• Oil Temperature: Measures from 50-350°F.
• Voltmeter: Displays a range of 7.0-25.5 volts (no sending unit required).
• Fuel Level: Displays Empty to Full in ¼ increments and is compatible with your Corvette’s existing GM fuel-sending unit.
• Integrated Indicators: Built-in turn signals and high-beam indicators keep you informed while driving.

Specifications:

• Gauge Dimensions: 3 3/8 inches in diameter, 1 ½ inches deep
• Available Display Colors: White, Red, Blue, and Green
• Speedometer Options: Order in MPH or KPH
• Accessories: All required sending and sensor units are included

Important Notes Before Purchase:

• LS Engine Compatibility: If your Corvette has an LS engine, you may need metric-to-standard adapters for the included sending units. These adapters may already be included in your engine kit; if not, they must be purchased separately.
• 4-Cylinder LS Engines: If your LS engine is a 4-cylinder, let us know at checkout so we can set the tachometer accordingly. The tachometer is programmable, so you can adjust it if needed.
• Bezel Not Included

Why Choose This Panel?

✔ Easy Installation
✔ Lifetime Warranty
✔ Unbeatable Value
✔ Perfect for Classic Corvette Owners

Upgrade your Corvette’s dash with cutting-edge digital precision while maintaining the classic look you love!
